Smart_Projector by SmartVision is the first and exclusive instrument designed to perform a complete and automatic check of wide range of components in a fast and easy way.
Smart_Projector 168
2D工业生产数字化测量机
“Smart_Projector 可以自动、客观、可重复性的、简易、快速的进行零件尺寸测量”
This machine is the revolutionary digital evolution of the traditional profile projector and micrometer caliper. It allows to check an unlimited number of measurements per item in just few seconds. There is no need for part alignment, no manual collimation nor focus and there are not moving components inside the Smart_Projector.
Smart_Projector provides objective and repeatable measurements and promptly show a « Pass / Fail » semaphore output, with no contribution nor interpretation by the operator, ensuring a full automatic evaluation and reporting of all control activities in compatible and ready-to-print Excel files (CSV, TSV, TXT), PDF and Image files.
Smart_Projector is a fast, compact, rugged, static, easy-to-use and easy-to-program device, designed for harsh environment and heavy duty cycle use.
- Specifically suited for massive (production) quality inspection, in-line control, incoming inspection
- Eliminates subjectivity and errors of operator-based gauging
- Increases number of quotas and quality check rate, up to 16000 checking features in a few seconds
- Performs a full automatic data report, available to processing by SPC software (Min, Max, Range, Average, Std Dev, 6 Sigma)
- Designed for in-production massive use
- Compact, Rugged and Fanless industrial case
- Plug-and-play, ready-to-use
- Suitable for unskilled operators use
- Ready for automation
- Clever investment with a fast Return on Investment
- Reduces time and costs of controls
| Measuring Chamber (mm) | 250×330 H.405 |
| Magnification | No |
| Field of View (FoV) (mm) | 168×113 |
| FoV Diagonal (mm) | 195 |
| FoV Area (mm2) | 18500 |
| Type of FoV | Rectangular with vignetting |
| Repeatability accuracy | ±1.5 μm |
| Measurement accuracy | ±8 μm |
| Layout usage | Vertical |
| Diascopic Light | Directional |
| Episcopic Light | Yes |
| Light receiving lens | Telecentric lens |
| Communication Interface | Gigabit Ethernet + USB 2 |
| Dimensions (mm) | 335×380 H.1255 |
| Weight (kg) | 41 |
| Case | Rugged stainless steel |
| Smart_Projector | Ruby | 7 | 29 | 55 | Quattro Pro | Double | 108 | 168 | 224 |
| Image preview |  |
 |
 |
 |
 |
 |
 |
 |
 |
| Layout usage | Vertical | Vertical | Vertical | Vertical Horizontal |
Vertical Horizontal |
Vertical Horizontal |
Vertical Horizontal |
Vertical | Vertical |
| Magnification | No | No | No | No | 4 steps | 2 steps | No | No | No |
| Field of View (FoV) (mm) | 2.2×1.7 | 7×4.5 | 29×19 | 55×37 | ø 12 | 24 | 48 | 90 | 60×45 | 108×73 | 108×73 | 168×113 | 224×150 |
| FoV Diagonal (mm) | 2.78 | 8 | 30 | 60 | – | 75 | 125 | 125 | 195 | 235 |
| FoV Area (mm2) | 3.74 | 31 | 530 | 2000 | 112 / 452 / 1800 / 6360 | 2700 | 7800 | 7800 | 18500 | 32550 |
| Diascopic Light | Collimated | Collimated | Collimated | Collimated | Collimated | Collimated | Collimated | Directional | Directional |
| Episcopic Light | Yes | No | No | Yes | Yes | Yes | Yes | Yes | No |
- Automatic feature recognition
- Software programmable light
- Quick Annotate and markup
- CAD import / export (dxf file)
- Automatic data report export (xlsx, csv, tsv, txt)
- Print report (pdf)
- Multi language interface
Precision Clamps
Support Glasses
Barcode Scanner CCD
[cq_vc_hotspot image=”8603″ isdisplayall=”on” icontype=”icon” fonticon=”” position=”25%|44%,35%|44%,45%|44%,60%|44%,75%|44%,85%|44%” iconbackground=”#efefef” circlecolor=”#ffffff” arrowposition=”left,left,left,left,left,left,left” tooltipstyle=”light” maxwidth=”350″][hotspotitem]
Rugged stainless steel industrial case
Compact static equipment
[/hotspotitem]
[hotspotitem]
Industrial high resolution camera
High performance Bi-Telecentric Optics
[/hotspotitem]
[hotspotitem]
Software programmable
Episcopic Light (4 independent sectors)
[/hotspotitem]
[hotspotitem]
Protected Two Side Open measuring chamber
Easy object placement
Height-adjustable interchangable glass
Customizable loading plate
[/hotspotitem]
[hotspotitem]
Software programmable
Collimated Diascopic Light
[/hotspotitem]
[hotspotitem]
Suitable for the production line
Ready for Automation
[/hotspotitem][/cq_vc_hotspot]
Rugged stainless steel industrial case
Compact static equipment
[/hotspotitem]
[hotspotitem]
Industrial high resolution camera
High performance Bi-Telecentric Optics
[/hotspotitem]
[hotspotitem]
Software programmable
Episcopic Light (4 independent sectors)
[/hotspotitem]
[hotspotitem]
Protected Two Side Open measuring chamber
Easy object placement
Height-adjustable interchangable glass
Customizable loading plate
[/hotspotitem]
[hotspotitem]
Software programmable
Collimated Diascopic Light
[/hotspotitem]
[hotspotitem]
Suitable for the production line
Ready for Automation
[/hotspotitem][/cq_vc_hotspot]
Smart_Projector 168
[cq_vc_hotspot image=”11149″ isdisplayall=”on” icontype=”icon” position=”55%|68%,60%|68%,66%|68%,72%|68%,77.5%|68%” iconbackground=”#b2b2b2″ circlecolor=”#ffffff” arrowposition=”right,right,right,right,right” tooltipstyle=”light” maxwidth=”350″ marginoffset=”-6px 0 0 -6px”][hotspotitem]
Powerful All-In-One PC
[/hotspotitem][hotspotitem]
HD Touchscreen
Intuitive measurement software
[/hotspotitem][hotspotitem]
Record programs
with a finger touch
[/hotspotitem][hotspotitem]
Automatic feature
recognition
[/hotspotitem][hotspotitem]
Up to 16.000 features
per item
[/hotspotitem][/cq_vc_hotspot]
Powerful All-In-One PC
[/hotspotitem][hotspotitem]
HD Touchscreen
Intuitive measurement software
[/hotspotitem][hotspotitem]
Record programs
with a finger touch
[/hotspotitem][hotspotitem]
Automatic feature
recognition
[/hotspotitem][hotspotitem]
Up to 16.000 features
per item
[/hotspotitem][/cq_vc_hotspot]
Powerful All-in-One PC
